Model: AD-4214N
INPUT: 100-240V~ 1.0-0.5A, 50-60Hz
OUTPUT: 14V 3.0A 42W
Connecter size: Int. Diameter: 4.30mm
Ext. Diameter: 6.50mm
Length : 10.00mm
Pin : 1.40mm
Dimension: 108 x 62 x 30 mm
*Please take note, 3 wire IEC C13 AC power cord not included.
**For use with Flat Panel LCD Display Monitors 1701 1702 & 1900FP.
PA-21 Family,
INPUT: 100-240V~ 1.6A, 50-60Hz
OUTPUT: 19.5V 3.34A 65W
Octagonal Connecter size: Int. Diameter: 5.00mm
Ext. Diameter: 7.50mm
Signal Pin in the Middle
Dimension: 106 x 47 x 29 mm
*Please take note, 3 wire AC power cord not included.
AC Adapter Model: ADP-180BB B
Acer P/N: AP.18001.001
INPUT: 100-240V~ 2.5A, 50-60Hz
OUTPUT: 19V 9.5A 180W
Connector: 4-pin DIN
Dimensions: 170 x 85 x 40 mm
*Please take note, 3-wire (IEC C13) AC power cord not included.
Model: ADP-30JH B
Acer P/N: AP03001001 , AP.03001.001
INPUT: 100-240V~ 1.0A, 50-60Hz
OUTPUT: 19V 1.58 30W
Connecter size: Int. Diameter: 1.70mm
Ext. Diameter: 5.50mm
Length : 11.00mm
Dimension: 90 x 42 x 28 mm
*Please take note, 3 wire AC power cord not included.
