Server Part & AC Adapter

AC Adapter Model: PA-1151-03MS

INPUT: 100-240V~ 2.0A, 50-60Hz
OUTPUT: 19V 7.9A 150W

AC Adapter Model: PA-1151-05

INPUT: 100-240V~ 2.25A, 50-60Hz
OUTPUT: 12V 12.5A 150W
Connector: 4-pin DIN

Dimensions: 168 x 83 x 40 mm

*Please take note, IEC AC power cord not included.

AC Adapter Model: PA-1161-02
P/N: 76-011161-4D

INPUT: 100-240V~ 2.25A, 50-60Hz
OUTPUT: 20V 8.0A 160W
Connector: 4-pin DIN

Dimensions: 180 x 67 x 42 mm

*For use with Laptop under 258SA, 258KA, 766, L373N1 notebook series:
- Alienware Area-51m 766
- Clevo 5620D
- PortaNote 5600D
- ViewBook VB1500S

*Please do not mix up with another adapter with the same model number but different connector size, please check carefully the connector's measurement of your adapter.

**Please take note, 3 wire AC power cord not included.

AC Adapter Model: PA-1161-02
P/N: 76-011161-4D

INPUT: 100-240V~ 2.25A, 50-60Hz
OUTPUT: 19V 8.4A 160W
Connector: 4-pin DIN

Dimensions: 180 x 67 x 42 mm

*For use with the following Notebook Series:
- Acer Aspire 1700 Series
- Alienware Area-51M 5500 Series model 766
- ViewSonic Viewbook 1500S, 1500P

*Please take note, 3 wire AC power cord not included.

Model: PA-1300-04
Acer P/N: AP03003001 , AP.03003.001

INPUT: 100-240V~ 1.0A, 50-60Hz
OUTPUT: 19V 1.58 30W
Connecter size: Int. Diameter:  1.70mm
                       Ext. Diameter:  5.50mm
                       Length           : 11.00mm

Dimension: 90 x 35 x 26 mm

*Please take note, 3 wire AC power cord not included.
